● Input Current: 32A
● Max Output Power: 7kW / 22kW
● Max Output Current: 32A(1-Phase) / 32A(3-Phase)
● Connector: CCS2
● Protection Degree: IP54
● Charging Method: Plug in & Charge / RFID Card / APP
● Communication Method: WIFI / 4G
● Certification: CE / CB / UKCA
● Warranty: 2-Year
| Model | OR-LCS Series | |||||
| Power | 2*7kW | 2*22kW | ||||
| Power Supply | 1P+N+PE | 3P+N+PE | ||||
| Input/Output Voltage | AC 230V±15% | AC 400V±15% | ||||
| Input/Output Current | 2* Max.32A (1-Phase) | 2* Max.32A (3-Phase) | ||||
| Connector | 2* Type2 Socket | |||||
| Leakage Protection | AC30mA+DC6mA | |||||
| Plug in and Charge | Optional | |||||
| APP | Optional | |||||
| RFID | Optional | |||||
| Communication Method | 4G ; WIFI | |||||
| Charging Method | APP ; RFID card ; Plug in & Charge | |||||
| OCPP 1.6J | Supported | |||||
| Current Adjusting | Supported | |||||
| Certification | CE ; CB ; UKCA | |||||
| All-round Protection | Over current protection; Ground protection; Surge protection; Over/Under voltage protection; Over temperature protection | |||||
| Ingress Protection | IP54 | |||||
| Rated Frequency | 50/60Hz | |||||
| Installation | Pile | |||||
| Application Scene | Outdoor | |||||
| Work Temperature | -25~50℃ | |||||
| Work Humidity | 5%~95% non condensation | |||||
| Maximun Altitude | ＜2000m | |||||
| Product Dimension | 1200*250* 250（H*W*D）mm | |||||
| External Package | Carton | |||||
