● Input Current: 124A / 186A / 248A
● Max Output Power: 80kW / 120kW / 160kW
● Max Output Current: 250A DC
● Connector: CCS2 / CCS1 / CHAdeMO / GB/T
● Protection Degree: IP54
● Charging Method: RFID Card / OCPP1.6J / Small Program Scan Code
● Communication Method: 4G / WIFI / LAN (Optional)
● Certification: CE
● Warranty: 2-Year
| Specification | Model | OR-FSW-DC 80-160kW Series | ||
| Connector and Electrical | Input Current | 124A | 186A | 248A |
| Input Voltage | 260-480V AC | |||
| Output Power | 80kW | 120kW | 160kW | |
| Output Current | 250A | |||
| Output Voltage | 150～1000V DC | |||
| Charging Cable Length | 5m / 7m / 8m (customization) | |||
| Connector Type | CCS2 / CCS1 / CHAdeMO / GB/T | |||
| Standby Power Consumption | <30W | |||
| Performance and Safety | Ingress Protection | IP54 | ||
| Work Temperature | -20°C ~ +50°C | |||
| Work Humidity | 5%-95% | |||
| Certifications | CE | |||
| Function | Charging Method | RFID / OCPP1.6J / Small Program Scan Code | ||
| Communication Method | 4G / WIFI / LAN (Optional) | |||
| LCD Display | 7-inch Touch Screen | |||
| Installation | Floor Mounted | |||
