● Input Current: 124A / 186A / 248A / 279A
● Max Output Power: 80kW / 120kW / 160kW / 180kW
● Max Output Current: 250A DC
● Connector: CCS2 / CCS1 / CHAdeMO / GB/T
● Protection Degree: IP54
● Charging Method: RFID Card / OCPP1.6J
● Communication Method: 4G
● Certification: CE / UKCA
● Warranty: 2-Year
| Specification | Model | OR-FS-DC 80-180kW Series | |||
| Connector and Electrical | Input Current | 124A | 186A | 248A | 279A |
| Input Voltage | 260-480V AC | ||||
| Output Power | 80kW | 120kW | 160kW | 180kW | |
| Output Current | 250A | ||||
| Output Voltage | 150～1000V DC | ||||
| Charging Cable Length | 6m (customization) | ||||
| Connector Type | CCS2 / CCS1 / CHAdeMO / GB/T | ||||
| Standby Power Consumption | <30W | ||||
| Performance and Safety | Ingress Protection | IP54 | |||
| Work Temperature | -25°C ~ +50°C | ||||
| Work Humidity | 5%-95% | ||||
| Certifications | CE, UKCA | ||||
| Function | Charging Method | RFID / OCPP1.6J | |||
| Communication Method | 4G | ||||
| LCD Display | Yes | ||||
| Installation | Floor Mounted | ||||
