● Input Current: 93A
● Max Output Power: 60kW
● Max Output Current: 200A
● Connector: CCS2
● Protection Degree: IP54
● Charging Method: RFID Card / OCPP1.6J
● Communication Method: 4G
● Certification: CE / UKCA
● Warranty: 2-Year
| Specification | Model | OR-FS-DC 60kW Series |
| Connector and Electrical | Input Current | 93A |
| Input Voltage | 230 / 400V AC | |
| Output Power | 60kW | |
| Output Current | 200A | |
| Output Voltage | 200～1000V DC | |
| Charging Cable Length | 6m (customization) | |
| Connector Type | CCS2 | |
| Standby Power Consumption | <30W | |
| Performance and Safety | Ingress Protection | IP54 |
| Work Temperature | -25°C ~ +50°C | |
| Work Humidity | 5%-95% | |
| Certifications | CE, UKCA | |
| Function | Charging Method | RFID / OCPP1.6J |
| Communication Method | 4G | |
| LCD Display | Yes | |
| Size and Weight | Product Size | 960mm*690mm*300mm |
| External Package | Carton |
