● Input Current: 310A / 372A / 465A
● Max Output Power: 200kW / 240kW / 300kW
● Max Output Current: 250A DC
● Connector: CCS2 / CCS1 / CHAdeMO / GB/T
● Protection Degree: IP54
● Charging Method: RFID Card / OCPP1.6J
● Communication Method: 4G
● Certification: CE / UKCA
● Warranty: 2-Year
| Specification | Model | OR-FS-DC 200-300kW Series | ||
| Connector and Electrical | Input Current | 310A | 372A | 465A |
| Input Voltage | 260-480V AC | |||
| Output Power | 200kW | 240kW | 300kW | |
| Output Current | 250A | |||
| Output Voltage | 150～1000V DC | |||
| Charging Cable Length | 6m (customization) | |||
| Connector Type | CCS2 / CCS1 / CHAdeMO / GB/T | |||
| Standby Power Consumption | <30W | |||
| Performance and Safety | Ingress Protection | IP54 | ||
| Work Temperature | -25°C ~ +50°C | |||
| Work Humidity | 5%-95% | |||
| Certifications | CE, UKCA | |||
| Function | Charging Method | RFID / OCPP1.6J | ||
| Communication Method | 4G | |||
| LCD Display | Yes | |||
| Installation | Floor Mounted | |||
